MÄDLERMÄDLER· Timing Belts and Pulleys
Timing belt pulley HTD 3M material aluminium 14 teeth for belt width 9mm
Manufacturer part no. 17021400
$13.99≈ 12.15 €
In stock — 3 unitslead time 14 d
Estimated landed cost
| Item | €12.15 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €5.43 |
| Total delivered | €32.58 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 6.6 g |
Other characteristics
| Belt width | 9 mm |
| Bore | 6 mm |
| Hub diameter | 16 mm |
| No of teeth | 14 |
| Outer diameter of flanges | 16 mm |
| Outer diameter pulley | 12.61 mm |
| Pitch circle diameter | 13.37 mm |
| Total length | 17.5 mm |
| Version | 0 F |
| Material | Aluminum |
| Pilot hole | Without bore mm |
| Profile | HTD 3M |
| Surface | Blank |
Description
Material: Aluminium similar EN AW2017A. Flanges zinc-plated steel. The functionability of a belt drive is largely influenced by the quality of the used pulley. HTD pulleys are precision components, manufactured pitch-true with special cutters. This leads to a precise meshing of teeth.
