Timing belt pulley HTD 8M material steel 38 teeth for belt width 50mm
Manufacturer part no. 17441900
$74.06≈ 64.32 €
In stock — 1 unitslead time 14 d
Estimated landed cost
| Item | €64.32 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €15.86 |
| Total delivered | €95.18 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 3.3 kg |
Other characteristics
| Belt width | 50 mm |
| Bore | 45 mm |
| Hub diameter | 75 mm |
| No of teeth | 38 |
| Outer diameter of flanges | 103 mm |
| Outer diameter pulley | 95.39 mm |
| Pilot hole | 14 mm |
| Pitch circle diameter | 96.77 mm |
| Total length | 70 mm |
| Version | 1 F |
| Material | Steel |
| Profile | HTD 8M |
| Surface | Phosphated |
Description
Material: Up to a teeth number of 72 phosphated steel, from a teeth number of 80 phosphated grey cast iron GG25. The functionability of a belt drive is largely influenced by the quality of the used pulley. HTD pulleys are precision components, manufactured pitch-true with special cutters. This leads to a precise meshing of teeth.
