MÄDLERMÄDLER· Spur Gears, Toothed Racks, Internal Gears, Ratchet Wheels
Spur gear made of plastic PA12G black with steel core module 3 15 teeth tooth width 30mm outside diameter 51mm
Manufacturer part no. 23355215
$101.26≈ 87.94 €
In stock — 1 unitslead time 14 d
Estimated landed cost
| Item | €87.94 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €20.59 |
| Total delivered | €123.53 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 204 g |
Other characteristics
| Bore diameter | 10 mm |
| Hub diameter | 35 mm |
| Hub length | 20 mm |
| Max torque | 5.8 Nm |
| Module | 1.59 |
| No of teeth | 15 |
| Outer diameter | 51 mm |
| Pitch circle diameter | 45 mm |
| Tooth quality | 8 |
| Tooth width | 30 mm |
| Hardened | No |
| Hub | One sided |
| Material | Plastic (PA12) with steel core |
| Surface | Blank |
Description
Material: Outer part: Plastic PA 12 G black with steel core. Milled, straight teeth. Tooth quality 8e25 DIN 3967. Temperature range -60°C to +120°C, short periods 150°C. – Special plastic with excellent material properties. – Enables snugly fitting, high strength shaft-hub connection. – Optimal force transmission due to cylindrical contact area. – Light, silent and clean, with excellent dry running properties.
