MÄDLERMÄDLER· Bevel Gears, Worm Wheels, Worms
Worm wheel made of cast iron GG25 module 3 52 teeth double-thread right hand
Manufacturer part no. 31022100
$194.58≈ 168.98 €
In stock — 1 unitslead time 14 d
Estimated landed cost
| Item | €168.98 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €36.80 |
| Total delivered | €220.78 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 3.4 kg |
Other characteristics
| Bore | 30 mm |
| Max torque | 242 Nm |
| No of teeth | 52 |
| Outer diameter | 165 mm |
| Material | Grey cast iron (A48) |
| Module | 3 double-thread RH |
| Ratio | 26 : 1 |
| Surface | Blank |
Description
Material: GG25, with milled out, hollow teeth. With double-sided hub. Double-thread worm gears to be paired with double-thread worms. If the module (and number of threads) are matching, various ratios at various axle distances can be realized. Pressure angle 20°. Efficiency: approx. 0,66. Not self-locking.
