Ball flange bearing SSBPF 203 bore 17mm bearing and two-part housing from stainless steel
Manufacturer part no. 62699417
$43.54≈ 37.81 €
In stock — 3 unitslead time 14 d
Estimated landed cost
| Item | €37.81 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €10.56 |
| Total delivered | €63.37 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 270 g |
Other characteristics
| Admissible load of housing | 2.65 kN |
| Bearing load rating dyn c | 9.6 kN |
| Bearing load rating stat c0 | 4.8 kN |
| Bore | 17 mm |
| Material | Stainless steel |
| Surface | Blank |
| Type | SSBPF 203 |
Description
Material: Housing from two-part sheets: Stainless steel 1.4305 (X5CrNi18-10, AISI 304). Rolling bearing: Stainless steel 1.4125 (X105CrMo17, AISI 440 C), lubricated with grease FM 222 for food processing machinery, with registration FDA, CIFA, KPF2K-20, NSF H1. Temperature range: -20°C to +90°C (for short time up to +120°C). With 3 mounting holes. The rolling bearing can be swiveled when mounting to compensate shaft misalignement. The shaft will get fastened with 2 setscrews. Lubricated for life at normal operating conditions. Re-lubricating is not possible.
