Spherical bearing DIN ISO 12240-1-K type GD without outer ring maintenance-free bore 20mm outer diameter 40mm
Manufacturer part no. 63332000
$33.17≈ 28.81 €
In stock — 8 unitslead time 14 d
Estimated landed cost
| Item | €28.81 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €8.76 |
| Total delivered | €52.57 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 142 g |
Other characteristics
| Bearing shell width | 18 mm |
| Inner diameter | 20 mm |
| Outer diameter | 40 mm |
| Tilt angel | 14 ° |
| Total width | 25 mm |
| Material | Steel |
| Surface | Polished / Zinc-plated |
Description
Material: Inner ring bearing steel 100Cr6, hardened, ground and polished. Bearing shell steel 9SMnPb28K, zinc plated, with PTFE-lining. Dimensions according to DIN ISO 12240-1 (DIN 648) series K (wide version). Maintenance-free. Suitable for high dynamic loads. Without outer ring (smaller outer diameter than version S or S…D).
