MÄDLERMÄDLER· Rod Ends, Spherical Bearings, Clevises, Clevis Joints, Angle Joints
Spherical bearing DIN ISO 12240-1-K type G without outer ring relubricateable bore 22mm outer diameter 42mm stainless steel == Initial lubrication required before use ==
Manufacturer part no. 63399222
$100.44≈ 87.23 €
In stock — 2 unitslead time 14 d
Estimated landed cost
| Item | €87.23 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €20.45 |
| Total delivered | €122.68 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 168 g |
Other characteristics
| Bearing shell width | 20 mm |
| Inner diameter | 22 mm |
| Outer diameter | 42 mm |
| Tilt angel | 15 ° |
| Total width | 28 mm |
| Material | Stainless steel / Brass |
| Surface | Polished |
Description
Material: Inner ring stainless steel 1.4034 (AISI 440 C), hardened, ground and polished. Bearing shell special brass CuZn38Al1. Dimensions according to DIN ISO 12240-1 (DIN 648) series K (wide version). Can be re-lubricated (from size 6mm with lubricatin hole). Initial lubrication required before use For high sliding speed up to 60 m/min. Without outer ring (smaller outer diameter than version S or S…D).
