Precision worm wheel centre distance 80mm i=20 40 teeth

MÄDLERMÄDLER· Mechanics & transmission

Precision worm wheel centre distance 80mm i=20 40 teeth

Name: Precision worm wheel centre distance 80mm i=20 40 teeth
Brand: MÄDLER
Price: 446.84 USD
Availability: BackOrder

Manufacturer part no. 33062000

$446.84≈ 387.14 €

Price summary

Listed by MÄDLER at €387.14. Delivered to France, including shipping, VAT and any customs duty, it comes to about €482.57. Prices last checked on 2026-08-07.

Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.

On backorderlead time 14 d

View at seller ↗

Estimated landed cost

Landed cost breakdown
Item	€387.14
Shipping	€15.00
VAT (20%)	€80.43
Total delivered	€482.57

Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.

Datasheets & documents

Specifications (automatically extracted)

Mechanical

Weight

3.033 kg

Other characteristics

Max torque	296 Nm
Module	3
No of teeth	40
Outer diameter	130.5 mm
Helix angle	8°58 °
Material	Brass
Ratio	20 : 1
Surface	Blank

Description

Material: Special brass CuZn37Mn3Al2PbSi/So. Pressure angle 15°. The gear wheels can only be used with worms having the same centre distance and the same transmission. Can be built into gear systems, no reworking required, thus short assembly times. * The figures stated for the efficiency are only reference values, since – besides the lead angle – also mounting, lubrication, speed and assembly have an influence on the efficiency.
