MÄDLERMÄDLER· Bevel Gears, Worm Wheels, Worms
Bevel gear made of brass Ms58 module 1 15 teeth i=2:1 milled
Manufacturer part no. 35055600
$27.08≈ 23.52 €
In stock — 6 unitslead time 14 d
Estimated landed cost
| Item | €23.52 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €7.70 |
| Total delivered | €46.22 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 9 g |
Other characteristics
| Bore | 5 mm |
| Max torque | 9.4 Ncm |
| Module | 1 |
| No of teeth | 15 |
| Optional counter wheel part no | 35 055 700 |
| Outer diameter | 17.4 mm |
| Tooth quality | 8 |
| Material | Brass (Ms58) |
| Ratio | 2:1 (30/15) |
| Surface | Blank |
Description
Material:Brass Ms58 (2.0401). Milled teeth. Shaft angle = 90°. The bevel gears only run as a pair at the stated ratio. Note for ordering: These gears are sold singulary, not by pair. For a pair of bevel gears, you have to order two matching gears of the same module and ratio. At ratio 1:1, you need two pieces of the same number of teeth. At ratio uneven 1:1, you need two pieces with a different number of teeth of the same ratio.
