MÄDLERMÄDLER· Motors & actuators
Miniature spur gear motor SF with DC-motor 24V i=250:1 idle speed 27 /min
Manufacturer part no. 43046324
$122.07≈ 105.76 €
Price summary
Listed by MÄDLER at €105.76. Delivered to France, including shipping, VAT and any customs duty, it comes to about €144.91. Prices last checked on 2026-08-07.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
On backorderlead time 14 d
Estimated landed cost
| Item | €105.76 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €24.15 |
| Total delivered | €144.91 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Electrical
| Voltage | 24 V |
Mechanical
| Weight | 200 g |
Other characteristics
| Nominal current | 0.4 A |
| Nominal power | 2.99 W |
| Nominal torque | 1.3 Nm |
| Nominal voltage | 24 V |
| Tightening torque | 1.6 Nm |
| Idle speed | 27.0 min-1 |
| Nominal speed | 22.0 min-1 |
| Ratio | 250:1 |
Description
Housing: Steel, zinc-plated. Can be mounted in any position. Teeth: Steel gears. Bearing: Sintered bronze plain bearings. Lubrication: Maintenance free grease lubrication. Motor: DC motor 24 V. motor speed 6500 rpm, interference-free. Change the direction of rotation by switching the polarity. Protection class acc. to EN 60529: IP 20. Operating mode as per VDE 0530: S2-10 min. Permissible ambient operating temperature: -10 to +60°C. Ideal drive for short term operation, e.g. for actuating device.
