MÄDLERMÄDLER· Mechanics & transmission
Travel-wheel system RB/I size 200 with PUR-bandaged wheel case length 250mm
Manufacturer part no. 48020084
$1412.24≈ 1222.30 €
Price summary
Listed by MÄDLER at €1222.30. Delivered to France, including shipping, VAT and any customs duty, it comes to about €1484.76. Prices last checked on 2026-08-05.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
On backorderlead time 56 d
Estimated landed cost
| Item | €1222.30 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €247.46 |
| Total delivered | €1484.76 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 15.1 kg |
Other characteristics
| Payload 240 m min. | 700 kg |
| Payload up to 100 m min. | 1 200 kg |
| Size | 200 |
| Partno buffer set | 480 710 84 |
| Partno roller guide | 480 210 84 |
| Partno set of bolts | 480 221 84 |
| Type | K (with bandage) |
Description
Material: Housing made of spharoidal graphite cast iron, painted gray. Travel wheel made of GGG 70, with high-quality roller bearing. Version G: With cast iron travel wheel with two flanges, with high load capacity, to be used on rails. Version K: With cast iron travel wheel with PUR-bandage (Polyurethane-Elastomer), for higher traction at low oprating noise. A very robust, universal, maintenance-free travel wheel system available in two sizes. It is designed for various travel applications with wheel loads up to 3.5 t and travel speeds up to 240 m/min (depending on version and load). It can even be used at extreme ambient temperatures from -20 °C to +60 °C. Engineers who want to develop their own drive systems can also achieve fast and reliable solutions using the versatile modular construction system. The five connection surfaces are machined and provide for a multitude of connection variants. 4 screws for inverted mounting are supplied. The housing is painted gray (RAL 7001) and can be repainted. The travel-wheel systems can be combined with the geared motors RBM/I to form a compact drive unit.
