MÄDLERMÄDLER· Mechanics & transmission
SKF self aligning ball bearing 2209 E-2RS1TN9 double row inner diameter 45mm outer diameter 85mm width 23mm sealed
Manufacturer part no. 64773084
$161.04≈ 139.85 €
Price summary
Listed by MÄDLER at €139.85. Delivered to France, including shipping, VAT and any customs duty, it comes to about €185.82. Prices last checked on 2026-08-05.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
On backorderlead time 14 d
Estimated landed cost
| Item | €139.85 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €30.97 |
| Total delivered | €185.82 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 530 g |
Other characteristics
| Inner diameter | 45 mm |
| Load rating dynamic | 22.9 kN |
| Outer diameter | 85 mm |
| Static load rating | 7.8 kN |
| Width | 23 mm |
| Material | Roller bearing steel |
| Skf type | 2209 E-2RS1TN9 |
| Speed limit | 5300 min-1 |
| Surface | Blank |
| Version | Sealed |
Description
Material: Bearing steel. Self aligning ball bearings in premium-quality. – For middle-high, common axial and radial load. – Usable at angular displacement. – Usable for high speed. Temperature range: -30°C to +90°C (for short time up to +110°C). Other versions or other bearing types on request.
