Spring plunger M10 type ASNV with ball and internal hexagon strong tension stainless steel 1.4305
Manufacturer part no. 65499670V
$20.75≈ 17.96 €
Price summary
Listed by MÄDLER at €17.96. Delivered to France, including shipping, VAT and any customs duty, it comes to about €39.55. Prices last checked on 2026-08-05.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
On backorderlead time 14 d
Estimated landed cost
| Item | €17.96 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €6.59 |
| Total delivered | €39.55 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 14 g |
Other characteristics
| D2 | 6 mm |
| D3 | 16 mm |
| F2 | 103.5 N |
| L1 | 23 mm |
| L2 | 17 mm |
| S | 2 mm |
| Spring load f1 | 57 N |
| Sw | 5 mm |
| D1 | M10 |
| L3 | – |
Description
Material type ASNV: Body: Stainless steel Ball: Stainless steel, hardened Spring: Stainless steel, strong spring tension. Used for fixation and to press something in or push it out. Temperature range: -40ºC to +250ºC. * Statistical average
