Heavy duty transport castor with plate PU bandage aluminium wheel fixed castor wheel Ø 100
Manufacturer part no. 77763100H
$57.12≈ 49.60 €
Price summary
Listed by MÄDLER at €49.60. Delivered to France, including shipping, VAT and any customs duty, it comes to about €77.52. Prices last checked on 2026-08-05.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
On backorderlead time 14 d
Estimated landed cost
| Item | €49.60 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €12.92 |
| Total delivered | €77.52 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 1.2 kg |
Other characteristics
| B | 40 mm |
| D | 100 mm |
| H | 137 mm |
| Load capacity | 280 kg |
| M | 83 mm |
| M1 | 65 mm |
| N | 73 mm |
| N1 | 53 mm |
| P | 105 mm |
| P1 | 87 mm |
| Suitable swivel castor part number | 77 761 100 H |
| Suitable swivel castor with brakes part number | 77 762 100 H |
| N2 | – |
Description
Material: Fork: steel plate, zinc-plated. Tread: Prothane®, cast polyurethane 95 +/-3° Shore A. Wheel body: aluminium, screwed. Wheel mounting: ball bearing. For indoor and outdoor use. Suitable for high loads. Non-marking and abrasion resistant. Good resistance to oil, grease, petrol and chemicals. Temperature range: -20°C to +70°C. * Width of the castor ** No long hole, bore with Ø d
