STMicroelectronics STSPIN220 — LOW VOLTAGE STEPPER MOTOR DRIVER
Manufacturer part no. STSPIN220
€1.73
In stock — 7797 unitslead time 175 d
- Conforme à RoHS 3
Estimated landed cost
| Item | €1.73 |
| Shipping | €18.00 |
| VAT (20%) | €3.95 |
| Total delivered | €23.68 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Volume pricing
| Qty | Unit price | Saving |
|---|---|---|
| ≥ 1 | €1.73 | |
| ≥ 10 | €1.27 | −26 % |
| ≥ 25 | €1.16 | −33 % |
| ≥ 100 | €1.03 | −40 % |
| ≥ 250 | €0.97 | −44 % |
| ≥ 500 | €0.94 | −46 % |
Datasheets & documents
Specifications (automatically extracted)
Electrical
| Current | 1.3 A |
Other characteristics
| Applications | Sur batterie |
| Boitier | 16-VFQFN plot exposé |
| Boitier fournisseur | 16-VFQFPN (3x3) |
| Configuration de sortie | Demi-pont (4) |
| Fonction | Variateur - entièrement intégré, commande et étage de puissance |
| Interface | Pas/direction |
| Resolution en pas | >256 micropas |
| Technologies | MOSFET de puissance |
| Temperature de fonctionnement | -40°C ~ 150°C (TJ) |
| Tension alimentation | 0V ~ 5V |
| Tension charge | 1,8V ~ 10V |
| Type de montage | Montage en surface |
| Type de moteur pas a pas | Bipolaire |
Compliance
| Moisture sensitivity (MSL) | 3 (168 heures) |
Description
MOSFET de puissance Pilote de moteur Bipolaire Pas/direction 16-VFQFPN (3x3)
