DigiKeyTexas Instruments· Sensors, transducers
Texas Instruments TMP117MAIDRVR — TEMPERATURE SENSOR
Manufacturer part no. TMP117MAIDRVR
€2.03
In stock — 8096 unitslead time 63 d
- Conforme à RoHS 3
Estimated landed cost
| Item | €2.03 |
| Shipping | €18.00 |
| VAT (20%) | €4.01 |
| Total delivered | €24.04 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Volume pricing
| Qty | Unit price | Saving |
|---|---|---|
| ≥ 1 | €2.03 | |
| ≥ 5 | €1.80 | −11 % |
| ≥ 10 | €1.72 | −15 % |
| ≥ 25 | €1.62 | −20 % |
| ≥ 50 | €1.55 | −23 % |
| ≥ 100 | €1.49 | −27 % |
| ≥ 500 | €1.37 | −33 % |
| ≥ 1,000 | €1.32 | −35 % |
Datasheets & documents
Specifications (automatically extracted)
Other characteristics
| Boitier | 6-WDFN plot exposé |
| Boitier fournisseur | 6-WSON (2x2) |
| Condition de test | 30°C ~ 45°C (0°C ~ 85°C) |
| Fonctionnalites | Mode veille, mode d'arrêt, non récurrent, limite programmable |
| Precision la plus elevee la plus faible | ±0,1°C (±0,2°C) |
| Resolution | 16 b |
| Temperature de detection locale | 0°C ~ 85°C |
| Temperature de fonctionnement | 0°C ~ 85°C |
| Tension alimentation | 1,8V ~ 5,5V |
| Type de capteur | Numérique, local |
| Type de montage | Montage en surface |
| Type de sortie | I2C/SMBus |
Compliance
| Moisture sensitivity (MSL) | 1 (illimité) |
Description
Capteur de température Numérique, local 0°C ~ 85°C 16 b 6-WSON (2x2)
Cheaper alternatives
Semantically close products available for less — check the specs match your need.
