Allegro MicroSystems ACS712ELCTR-05B-T — CURRENT SENSOR HE/OL 5A 8-SOIC

Name: Allegro MicroSystems ACS712ELCTR-05B-T — CURRENT SENSOR HE/OL 5A 8-SOIC
Brand: Allegro MicroSystems

Manufacturer part no. ACS712ELCTR-05B-T

€3.50

In stock — 20281 unitslead time 252 d

Conforme à RoHS 3

View at seller ↗

Estimated landed cost

Item	€3.50
Shipping	€18.00
VAT (20%)	€4.30
Total delivered	€25.80

Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.

Volume pricing

Qty	Unit price	Saving
≥ 1	€3.50
≥ 5	€3.13	−11 %
≥ 10	€2.99	−15 %
≥ 25	€2.83	−19 %
≥ 50	€2.71	−22 %
≥ 100	€2.61	−25 %
≥ 500	€2.40	−31 %
≥ 1,000	€2.33	−34 %

Datasheets & documents

📄 Datasheet

2 offers for this product

Save up to €1.96 — cheapest in-stock offer at €4.20 incl. VAT.

Seller	Availability	Price
DigiKey	In stock· lead time 252 d	€3.50€4.20 incl. VAT	Visit ↗
TMEBest delivered cost	In stock	€5.13€6.16 incl. VAT	Visit ↗

Prices compared incl. VAT: some sellers list ex-VAT trade prices, others VAT-inclusive retail prices. The badge marks the best estimated delivered cost, shipping and duties included — not always the first row.

Specifications (automatically extracted)

Electrical

Current	5 A
Current max.	0.013 A
Voltage	5 V

Other characteristics

Boitier fournisseur	8 -SOIC
Courant detection	5 A
Nombre de canaux	1
Sensibilite	185 mV/A
Temps de reponse	5 µs
Boitier	8-SOIC (szerokość 0,154po, 3,90mm)
Frequence	CC ~ 80kHz
Linearite	±1,5%
Polarisation	Bidirectionnelle
Pour la mesure	CA/CC
Precision	±1,5%
Sortie	Ratiométrique, Tension
Temperature de fonctionnement	-40°C ~ 85°C
Type de capteur	Effet Hall, Boucle ouverte
Type de montage	Montage en surface
