DigiKeyQuectel· RF and wireless
Quectel LC86GPAMD — RF RECEIVER 12-SMD MOD
Manufacturer part no. LC86GPAMD
€11.20
In stock — 562 unitslead time 98 d
- Conforme à RoHS 3
Estimated landed cost
| Item | €11.20 |
| Shipping | €18.00 |
| VAT (20%) | €5.84 |
| Total delivered | €35.04 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Volume pricing
| Qty | Unit price | Saving |
|---|---|---|
| ≥ 1 | €11.20 | |
| ≥ 10 | €9.73 | −13 % |
| ≥ 25 | €9.22 | −18 % |
| ≥ 100 | €8.53 | −24 % |
Datasheets & documents
Specifications (automatically extracted)
Other characteristics
| Debit de donnees max. | 921.6 Mbps |
| Sensibilite | -166 dBm |
| Boitier | Module 12-SMD |
| Boitier fournisseur | Module |
| Connecteur d antenne | Intégré, patch céramique |
| Fonctionnalites | Interface UART |
| Interface de donnees | UART |
| Modulation ou protocole | BeiDou, GLONASS, GNSS, GPS, QZSS |
| Temperature de fonctionnement | -40°C ~ 85°C |
| Tension alimentation | 2,55V ~ 3,6V |
| Type de montage | Montage en surface |
Compliance
| Moisture sensitivity (MSL) | 3 (168 heures) |
Description
null Récepteurs RF BeiDou, GLONASS, GNSS, GPS, QZSS -166dBm 921,6Mbps Intégré, patch céramique Module
