u-blox ANN-MB-00 — RF ANT GNSS/GPS 1.197-1.249GHZ
Manufacturer part no. ANN-MB-00
€53.96
In stock — 1747 unitslead time 140 d
- Conforme à RoHS
Estimated landed cost
| Item | €53.96 |
| Shipping (free over threshold) | Free |
| VAT (20%) | €10.79 |
| Total delivered | €64.75 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Volume pricing
| Qty | Unit price | Saving |
|---|---|---|
| ≥ 1 | €53.96 | |
| ≥ 10 | €40.49 | −25 % |
| ≥ 50 | €37.34 | −31 % |
Datasheets & documents
Specifications (automatically extracted)
Other characteristics
| Gain | 28 dB |
| Nombre d anneaux | 2 |
| Ros | 2 |
| Applications | BeiDou, Galileo, GLONASS, GNSS, GPS |
| Fonctionnalites | Câble - 5m, LNA |
| Frequence centre bande | 1,223GHz, 1,582GHz |
| Groupe de frequences | UHF (1GHz ~ 2GHz) |
| Hauteur max. | 0,886po (22,50mm) |
| Norme gamme rf | Navigation |
| Plage de frequences | 1,197GHz ~ 1,249GHz, 1,559GHz ~ 1,606GHz |
| Terminaison | SMA |
| Type d antenne | Module |
| Type de montage | Magnétique |
Compliance
| Moisture sensitivity (MSL) | 1 (illimité) |
Description
Antenne RF Module BeiDou, Galileo, GLONASS, GNSS, GPS 1,223GHz, 1,582GHz 1,197GHz ~ 1,249GHz, 1,559GHz ~ 1,606GHz 28dB SMA Magnétique
