DigiKeyIXYS· Discrete semiconductor products
IXYS MDD172-16N1 — DIODE MODULE GP 1600V 190A Y4-M6
Manufacturer part no. MDD172-16N1
€67.99
In stock — 43 unitslead time 168 d
- Conforme à RoHS 3
Estimated landed cost
| Item | €67.99 |
| Shipping (free over threshold) | Free |
| VAT (20%) | €13.60 |
| Total delivered | €81.59 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Volume pricing
| Qty | Unit price | Saving |
|---|---|---|
| ≥ 1 | €67.99 | |
| ≥ 12 | €51.44 | −24 % |
| ≥ 54 | €48.07 | −29 % |
| ≥ 102 | €45.35 | −33 % |
Datasheets & documents
Specifications (automatically extracted)
Electrical
| Current | 190 A |
Other characteristics
| Courant moyen redresse io par diode | 190 A |
| Tension cc inverse vr max. | 1 600 V |
| Boitier | Y4-M6 |
| Boitier fournisseur | Y4-M6 |
| Configuration de diode | 1 paire de connexions série |
| Courant fuite inverse a vr | 20 mA @ 1600 V |
| Technologies | Standard |
| Temperature de fonctionnement jonction | -40°C ~ 150°C |
| Tension directe vf max a if | 1.15 V @ 300 A |
| Type de montage | Montage sur châssis |
| Vitesse | Récupération standard >500ns, > 200mA (Io) |
Compliance
| Moisture sensitivity (MSL) | 1 (illimité) |
Description
Réseau de diodes 1 paire de connexions série 1600 V 190A Montage sur châssis Y4-M6
