DigiKeyRecom Power· Power supplies — board mount
Recom Power ROF-78E5.0-0.5SMD-R — DC DC CONVERTER 5V
Manufacturer part no. ROF-78E5.0-0.5SMD-R
€4.22
In stock — 13573 unitslead time 49 d
- Conforme à RoHS 3
Estimated landed cost
| Item | €4.22 |
| Shipping | €18.00 |
| VAT (20%) | €4.44 |
| Total delivered | €26.66 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Volume pricing
| Qty | Unit price | Saving |
|---|---|---|
| ≥ 1 | €4.22 | |
| ≥ 5 | €4.07 | −4 % |
| ≥ 10 | €4.00 | −5 % |
| ≥ 25 | €3.92 | −7 % |
| ≥ 50 | €3.85 | −9 % |
| ≥ 100 | €3.79 | −10 % |
| ≥ 250 | €3.71 | −12 % |
Datasheets & documents
Specifications (automatically extracted)
Electrical
| Current max. | 0.5 A |
| Voltage | 5 V |
Other characteristics
| Nombre de sorties | 1 |
| Rendement | 87 % |
| Tension entree max. | 36 V |
| Tension entree min. | 9 V |
| Tension sortie 1 | 5 V |
| Applications | ITE (commercial) |
| Boitier | Module 4-SMD |
| Fonctionnalites | SCP |
| Fonctionnalites de commande | Activation, actif haut |
| Taille dimension | 0,53po L x 0,49po l x 0,18po H (13,5mm x 12,5mm x 4,5mm) |
| Temperature de fonctionnement | -40°C ~ 75°C |
| Type | Module PoL non isolé |
| Type de montage | Montage en surface |
Compliance
| Moisture sensitivity (MSL) | 1 (illimité) |
Description
Module PoL non isolé Convertisseurs CC/CC 1 Sortie 5V 500mA 9V - 36V Entrée
