DFRobot FIT0277 — GEARMOTOR 146 RPM 12V LOW NOISE
Manufacturer part no. FIT0277
€41.88
In stock — 1 unitslead time 63 d
- Conforme à RoHS 3
Estimated landed cost
| Item | €41.88 |
| Shipping | €18.00 |
| VAT (20%) | €11.98 |
| Total delivered | €71.86 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Electrical
| Voltage | 12 V |
Mechanical
| Speed | 146 rpm |
Other characteristics
| Rapport de demultiplication | 51 |
| Diametre arbre | 0,236 po (6,00mm) |
| Espacement des orifices de montage | 1,100po (28,00mm) |
| Fonction | Motoréducteur |
| Longueur arbre et roulement | 0,709po (18,00mm) |
| Style de terminaison | Sortie pour montage sur circuit imprimé |
| Taille dimension | Rond - 1,417po de diamètre (36,00mm) |
| Tension nominale | 12V CC |
| Type | Moteur CC |
| Type de codeur | Incrémental |
Compliance
| Moisture sensitivity (MSL) | 1 (illimité) |
Description
Moteur CC Motoréducteur 146 tr/min Incrémental 12V CC
