Replacement chain for chain coupling type 5016 10 A-2 length 16 links including spring clip link vs Torsionally-stiff coupling HZ with blind hole bore 2mm max. torque 0.06 Nm outside diameter 6.4mm
Replacement chain for chain coupling type 5016 10 A-2 length 16 links including spring clip link and Torsionally-stiff coupling HZ with blind hole bore 2mm max. torque 0.06 Nm outside diameter 6.4mm are compared below on the data published by their sellers — price converted to euros, stock, and every specification either seller discloses. On price, Replacement chain for chain coupling type 5016 10 A-2 length 16 links including spring clip link is €10.72 cheaper ($12.89).
| Criterion |  Replacement chain for chain coupling type 5016 10 A-2 length 16 links including spring clip link |  Torsionally-stiff coupling HZ with blind hole bore 2mm max. torque 0.06 Nm outside diameter 6.4mm |
|---|---|---|
| Price | $12.89cheapest | $25.25 |
| Seller | MÄDLER | MÄDLER |
| Availability | In stock | In stock |
| Rating | — | — |
| Current | 10 A | — |
| Torque | — | 0.612 kg·cm |
| Weight | 490 g | 2.5 g |
| Bore diameter | — | 2 mm |
| Chain din | 10 A-2 | — |
| Coupling type | — | Torsionally stiff. transversal flexibility |
| Electrically insulating | — | Yes |
| Length incl connector | 254 mm | — |
| Material | Steel | Brass / Plastic |
| Max misalignment angular at 3000 min 1 | — | 0.5 |
| Max misalignment axial | — | 0.05 mm |
| Max misalignment radial at 3000 min 1 | — | 0.1 ±mm |
| Max speed | — | 3 U/min |
| Max torque | — | 0.06 Nm |
| Number of links incl connector | 16 | — |
| Outer diameter d1 mm | — | 6.4 mm |
| Spare disk partno | — | 601 237 00 |
| Stainless | — | Yes |
| Stat breaking torque | — | 0.7 Nm |
| Suitable for | 14 035 016 | — |
| Surface | Blank | Blank |
| Temperature max. | — | 60 °C |
| Temperature min. | — | -20 °C |
| Torsional stiffness | — | 10 Nm/rad |
| Total length | — | 12.7 mm |
| Type | 5 016 | — |
| With keyway | — | No |
| View at seller ↗ | View at seller ↗ |
Specifications are extracted automatically from seller data — an empty cell means the seller does not publish that value, not that the product lacks it.
Robotitem does not test products. This comparison reports seller-published data only, and ranking never takes affiliate commission into account.
