V-belt tensioner 1500N profile XPB, SPB and B (17) 3 grooves Dw 125mm
Manufacturer part no. 14085403
$530.85≈ 461.01 €
On backorderlead time 14 d
Estimated landed cost
| Item | €461.01 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €95.20 |
| Total delivered | €571.21 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 7.9 kg |
Other characteristics
| Center distance between tensioning wheel and mou | 175 mm |
| Flange diameter mounting side | 95 mm |
| Groove distance | 19 mm |
| Max tensioning area | 87.5 mm |
| Max tensioning force | 1 500 N |
| Number of grooves | 3 |
| Overhang screw head | 17 mm |
| Pulley width | 63 mm |
| Reference diameter | 125 mm |
| Tensioner | 4 |
| Total width of tensioner elements | 140 mm |
| Wrench size of tensioning axis | 27 mm |
Description
Material: Housings up to Ø 78 mm made of sintered steel, over Ø 78 mm made of grey cast iron GG20, lever St52, V-belt pulley cast steel. Matching narrow V-belts DIN 2215 und DIN 7753.Pulley with sealed ball bearings, permanently lubricated. Measur A of the pulley can be adjusted by distance-washers on the axis, which is screwd onto the tensioner. Can be used for both tensioning directions.
