MÄDLERMÄDLER· Mechanics & transmission
Precision worm wheel centre distance 17mm i=75 75 teeth
Manufacturer part no. 32007500
$59.16≈ 52.70 €
Price summary
Listed by MÄDLER at €52.70. Delivered to France, including shipping, VAT and any customs duty, it comes to about €81.24. Prices last checked on 2026-10-05.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
In stock — 2 unitslead time 14 d
Estimated landed cost
| Item | €52.70 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €13.54 |
| Total delivered | €81.24 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 26 g |
Other characteristics
| Max torque | 1.3 Nm |
| Module | 0.3 |
| No of teeth | 75 |
| Outer diameter | 24 mm |
| Helix angle | 1°28 ° |
| Material | Brass |
| Ratio | 75 : 1 |
| Surface | Blank |
Description
Material: Special brass CuZn37Mn3Al2PbSi/So. Pressure angle 15°. The gear wheels can only be used with worms having the same centre distance and the same transmission. * Worm only polished, worm gear with helical gearing. ** Worm with 9 mm hub diametre only. *** The figures stated for the efficiency are only reference values, since – besides the lead angle – also mounting, lubrication, speed and assembly have an influence on the efficiency.
