Bevel gear made of brass Ms58 module 1 60 teeth i=4:1 milled

MÄDLERMÄDLER· Mechanics & transmission

Bevel gear made of brass Ms58 module 1 60 teeth i=4:1 milled

Name: Bevel gear made of brass Ms58 module 1 60 teeth i=4:1 milled
Brand: MÄDLER
Price: 77.84 USD
Availability: InStock

Manufacturer part no. 35059300

$77.84≈ 67.37 €

Price summary

Listed by MÄDLER at €67.37. Delivered to France, including shipping, VAT and any customs duty, it comes to about €98.84. Prices last checked on 2026-08-05.

Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.

In stock — 6 unitslead time 14 d

View at seller ↗

Estimated landed cost

Landed cost breakdown
Item	€67.37
Shipping	€15.00
VAT (20%)	€16.47
Total delivered	€98.84

Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.

Datasheets & documents

Specifications (automatically extracted)

Mechanical

Weight

110 g

Other characteristics

Bore	6 mm
Max torque	48.8 Ncm
Module	1
No of teeth	60
Optional counter wheel part no	35 059 200
Outer diameter	60.3 mm
Tooth quality	8
Material	Brass (Ms58)
Ratio	4:1 (60/15)
Surface	Blank

Description

Material:Brass Ms58 (2.0401). Milled teeth. Shaft angle = 90°. The bevel gears only run as a pair at the stated ratio. Note for ordering: These gears are sold singulary, not by pair. For a pair of bevel gears, you have to order two matching gears of the same module and ratio. At ratio 1:1, you need two pieces of the same number of teeth. At ratio uneven 1:1, you need two pieces with a different number of teeth of the same ratio.
