MÄDLERMÄDLER· Locking Assemblies, Clamping Bushes, Taper Bushes
Bolt 5/8″ x 1 3/4″” for Taper bush 4030 and 4040
Manufacturer part no. 62251299
$5.02≈ 4.36 €
In stock — 10 unitslead time 14 d
Estimated landed cost
| Item | €4.36 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €3.87 |
| Total delivered | €23.23 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 89 g |
Other characteristics
| Length | 44.45 mm |
| Outer diameter | 15.88 mm |
| Suitable for clamping bushing type from | 4 030 |
| Suitable for clamping bushing type to | 4 040 |
| Thread pitch | 2.309 mm |
| Tightening torque | 170 Nm |
| Tolerance outer diameter | -0.25 mm |
| Tolerance wrench size | 0.27 mm |
| Wrench size | 12 mm |
| Material | Steel |
| Size inch | BSW 5/8 x 1 3/4 |
| Surface | Blank |
| Tolerance length | +/-1.0 mm |
Description
Material:Steel. Supply: One screw. Attention: Order quantity as needed. Up to size 3030, taper bushes have two screws, from 3525 three screws. Assembly instructions In this youtube video we show the mounting and demounting of taper bushes: Video clip (3.5 Minutes)
