MÄDLERMÄDLER· Cylinder Conveyor Rollers and Ball Transfer Units
Ball transfer unit 307 screwable plain bearing M16x50 balll and screw stainless steel bearing plastic
Manufacturer part no. 65430746
$23.76≈ 20.63 €
In stock — 5 unitslead time 14 d
Estimated landed cost
| Item | €20.63 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €7.13 |
| Total delivered | €42.76 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 71 g |
Other characteristics
| Ball overhang approx | 2.7 mm |
| Balldiameter | 8.5 mm |
| Length | 50 mm |
| Load rating at 0 5m sec | 38.64 N |
| Load rating at 1 5m sec | 12.88 N |
| Tightening torque | 3.21 Nm |
| Wrench size | 3 mm |
| Material | Stainless Steel |
| Surface | Blank |
| Thread size | M 16 mm |
Description
Material: Housing: Stainless Steel 1.4305 (AISI 303). Ball cup: Plastic. Ball: Stainless steel, hardened. Mini ball transfer unit, for example for material feeders for processing machines or packing machines. Orientation: anyway. Conveying speed max. 1.5m/sec. pv-value max. 0.34 Nm/mm² x m/sec. Temperature range -20°C to +90°C.
