Ball transfer unit 360 size 45 housing steel zinc plated
Manufacturer part no. 65436045
$82.64≈ 73.62 €
Price summary
Listed by MÄDLER at €73.62. Delivered to France, including shipping, VAT and any customs duty, it comes to about €106.34. Prices last checked on 2026-10-04.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
In stock — 1 unitslead time 14 d
Estimated landed cost
| Item | €73.62 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €17.72 |
| Total delivered | €106.34 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 720 g |
Other characteristics
| Load rating | 6 000 N |
| Outer diameter mounting surface | 62 mm |
| Outer diameter support surface | 75 mm |
| Overhang with ball | 19 mm |
| Overhang without ball | 10 mm |
| Size | 45 mm |
| Thickness of support surface | 4 mm |
| Total height | 53.5 mm |
| Material | Steel |
| Surface | Zinc-plated |
Description
Material Type 360: Housing: Steel, zinc-plated. Ball cup: Steel. Balls: Steel, hardened. Light duty ball transfer unit for medium high load. Orientation: Ball up or horizontal. Size 22 and 30 with felt seal. Without drain hole. Can be used with fixing clip. Conveying speed max. 1m/sec. Temperature range -20°C to +70°C. Note: Due to unevenness of the running surface, there are often only three rollers carrying the weight. Therefore the chosen load rating should equal at least one third of the load. Max. distance of ball transfer units = edge length of the object divided by 2.5.
