Revolving ball knob 3192 diameter 25mm
Manufacturer part no. 66452500
$9.60≈ 8.31 €
Price summary
Listed by MÄDLER at €8.31. Delivered to France, including shipping, VAT and any customs duty, it comes to about €27.97. Prices last checked on 2026-08-05.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
On backorderlead time 14 d
Estimated landed cost
| Item | €8.31 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €4.66 |
| Total delivered | €27.97 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 28 g |
Other characteristics
| Ball knob diameter | 25 mm |
| Handle length | 37.5 mm |
| Screw in length | 11 mm |
| Material | Plastic / Steel |
| Surface | Zinc-plated |
| Thread size | M 6 mm |
Description
Material: Duroplast PF31 black glossy finish. Bolt: Steel, zinc plated. Revolving ball knobs can be used instead of revolving handles, e.g., for handwheels and hand cranks. Revolving ball knobs have the same connecting dimensions as handles DIN 39 and DIN 98.
