MÄDLERMÄDLER· Mechanics & transmission
Polyamide hose PA (hard), color natural outer diameter 6mm, inner diameter 4mm
Manufacturer part no. 86980601
$1.76≈ 1.52 €
Price summary
Listed by MÄDLER at €1.52. Delivered to France, including shipping, VAT and any customs duty, it comes to about €19.82. Prices last checked on 2026-08-05.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
In stock — 10 unitslead time 14 d
Estimated landed cost
| Item | €1.52 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €3.30 |
| Total delivered | €19.82 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Other characteristics
| Inner diameter | 4 mm |
| Max operation pressure | 25 bar |
| Min bend radius | 30 mm |
| Outer diameter | 6 mm |
| Color | Nature mm |
| Material | Polyamide (PA) |
| Surface | Blank |
| Weight | 20 g/m |
Description
Material: Polyamide. Dimensions and tolerances to DIN 73378. Max. length 100m. Application: Pneumatic-hose for Pneufit-Push-In or Pneufit C connectors. PA-hoses allow a higher pressure than PU-hoses, but they need a bigger radius. Max. Operating Pressure: The pressures shown in the table are valid for -40°C up to +20°C. At higher temperature note follwing factors: Temperature 30 °C: Factor 0,83. Temperature 40 °C: Factor 0,72. Temperature 50 °C: Factor 0,64. Temperature 60 °C: Factor 0,57. Temperature 70 °C: Factor 0,47 (max. operating temperatur). 1 Unit = 1 Meter = 39.37 Inches
