MÄDLERMÄDLER· Pneumatic Elements
Spiral hose 8×12 length 0,72 – 8 mtr
Manufacturer part no. 87010808
$181.30≈ 157.45 €
In stock — 1 unitslead time 14 d
Estimated landed cost
| Item | €157.45 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €34.49 |
| Total delivered | €206.94 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 947 g |
Other characteristics
| Diameter coil | 65 mm |
| Max length | 8 m |
| Min length | 0.72 m |
| Fixed connection inch | G 3/8″ |
| Inner diameter x outer diameter | 8 x 12 mm |
| Material | Plastic (PU) / Brass |
| Surface | Nickel-plated |
| Swivel connection inch | G 3/8″ |
Description
Material: Polyurethane, flexible and extremely rugged. Fitting made from nickel-plated brass. The hose retracts to its original shape: the coils will not loose their original shape even under most adverse operating conditions. Data of fixed fitting on the supply side: PTFE pre-coated thread PVC coating to protect hose Data of the swivel connection on the side of the compressed-air tool: Swivelling joint with ball bearing Easy swivelling, even under pressure, no overstressing of hose coil.
