Clamp coupling (boc coupling) DIN 115 both sides bore 100mm with keyway material cast iron vs Elastic coupling DXA size 100 max. torque 11000Nm nominal torque 5500Nm outer diameter 220mm overall length 250mm with pilot bore
Clamp coupling (boc coupling) DIN 115 both sides bore 100mm with keyway material cast iron and Elastic coupling DXA size 100 max. torque 11000Nm nominal torque 5500Nm outer diameter 220mm overall length 250mm with pilot bore are compared below on the data published by their sellers — price converted to euros, stock, and every specification either seller discloses. On price, Elastic coupling DXA size 100 max. torque 11000Nm nominal torque 5500Nm outer diameter 220mm overall length 250mm with pilot bore is €467.98 cheaper ($886.43).
| Criterion |  Clamp coupling (boc coupling) DIN 115 both sides bore 100mm with keyway material cast iron |  Elastic coupling DXA size 100 max. torque 11000Nm nominal torque 5500Nm outer diameter 220mm overall length 250mm with pilot bore |
|---|---|---|
| Price | $1426.25 | $886.43cheapest |
| Seller | MÄDLER | MÄDLER |
| Availability | In stock | In stock |
| Rating | — | — |
| Weight | 63 kg | 29.3 kg |
| Bore diameter | 100 mm | — |
| Coupling type | Rigid two-piece stlye | Elastic. angular/transv./long flexible |
| Electrically insulating | No | No |
| Hub diameter | — | 160 mm |
| Material | Grey cast iron (A48) | Grey cast iron (A48) |
| Max alternating torque | — | 1 700 Nm |
| Max bore diameter | — | 100 mm |
| Max misalignment angle | 0 ° | 0.7 ° |
| Max misalignment axial | 0 mm | 2.4 mm |
| Max misalignment radial | 0 mm | 0.8 mm |
| Max speed | 920 min-1 | 3 100 U/min |
| Max torque | 5 400 Nm | 11 000 Nm |
| Nominal torque | — | 5 500 Nm |
| Number of allen bolts din 931 | 8 | — |
| Outer diameter | 250 mm | 220 mm |
| Pilot hole | — | 58 mm |
| Predecessor partno | — | 60 410 000 |
| Size | — | 100 |
| Spare spider 92 shore partno | — | 60 420 000 |
| Stainless | No | No |
| Surface | Blank | Blank |
| Temperature max. | 150 °C | 80 °C |
| Temperature min. | -40 °C | -20 °C |
| Total length | 350 mm | 250 mm |
| With keyway | Yes | No |
| View at seller ↗ | View at seller ↗ |
Specifications are extracted automatically from seller data — an empty cell means the seller does not publish that value, not that the product lacks it.
Robotitem does not test products. This comparison reports seller-published data only, and ranking never takes affiliate commission into account.
