MÄDLERMÄDLER· Mechanics & transmission
Spider (coupling insert) backlash-free 98 Shore A red size 38 outside diameter 80mm
Manufacturer part no. 60519838
$18.22≈ 15.79 €
Price summary
Listed by MÄDLER at €15.79. Delivered to France, including shipping, VAT and any customs duty, it comes to about €36.95. Prices last checked on 2026-08-07.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
On backorderlead time 14 d
Estimated landed cost
| Item | €15.79 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €6.16 |
| Total delivered | €36.95 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 49 g |
Other characteristics
| Max torque | 650 Nm |
| No of teeth | 8 |
| Nominal torque | 325 Nm |
| Outer diameter | 80 mm |
| Size | 38 |
| Stiffn radial | 4 400 N/mm |
| Tors spring stiffness dynam | 21 486 Nm/rad |
| Tors spring stiffness static | 7 160 Nm/rad |
| Material | Polyurethane (medium hard) |
| Surface | Blank |
Description
Material: Polyurethane, shore hardness 98° A (medium hard), red. Spiders (plastic inserts) for backlash-free elastic couplings (jaw couplings) like RNH, RNK, RNKC, connecting shafts RNW and foreign parts of the same kind from other suppliers. Medium hard type, for high torques. Temperature range -30°C to +100°C.
