MÄDLERMÄDLER· Couplings, Friction Clutches, Safety Couplings
Chain coupling pitch 1″x17,02mm 18 teeth nominal torque 1480Nm
Manufacturer part no. 14031600
$231.38≈ 200.94 €
In stock — 4 unitslead time 14 d
Estimated landed cost
| Item | €200.94 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €43.19 |
| Total delivered | €259.13 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 12.3 kg |
Other characteristics
| Hub diameter | 120 mm |
| Length of each sprocket | 60 mm |
| Max misalignment angle | 0.5 ° |
| Max misalignment axial | 0.25 mm |
| Max misalignment radial | 0.2 mm |
| Max outer diameter | 170 mm |
| Max torque | 1 480 Nm |
| Min bore diameter | 30 mm |
| Mounting distance over tooth flanks | 46.7 mm |
| Temperature max. | 220 °C |
| Temperature min. | -30 °C |
| Total length | 137 mm |
| Coupling type | Elastic. angular/transv./long flexible |
Description
Material: Steel, with double-strand chain DIN ISO 606 (ex DIN 8187). The couplings are delivered unassembled. The chain is packed seperately. Number of teeth = 18. -Elastic transmission of torque. -Fast declutching by simply loosening the chain. -Shafts do not need to be exactly aligned. -No axial shaft clearance permissible. Temperature range: -30°C to +220°C. *Selection according to the ratio of driving power to speed (P/n), the nominal torque must not be exceeded (incl. operating factor).
