MÄDLERMÄDLER· Gear Boxes and Geared Motors
Motorbase MB 38 x 300 for motors size 132 and 160
Manufacturer part no. 14059038
$1420.96≈ 1234.01 €
On backorderlead time 56 d
Estimated landed cost
| Item | €1234.01 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €249.80 |
| Total delivered | €1498.81 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 25.4 kg |
Other characteristics
| Hole diameter | M10/M10/13.0/13.0 mm |
| Hole distance for motor mounting length | 216/216/254/254 mm |
| Hole distance for motor mounting width | 140/178/210/254 mm |
| Material | Steel |
| Motor size iec | 132S/132M/160M/160L |
| Surface | Varnished |
| Type | RMW 38 |
Description
Material RMW 27: Steel parts painted blue, screws and other components zinc-plated. Material RMW 38: Steel parts, screws and other components zinc-plated. The motorbase are used to optimize belt drives. They ensure a constant belt tension and an even torque transmission. Switching off the system for manual post-tensioning is no longer necessary. The maintenance effort is minimized. Oscillation, vibrations and load peaks are absorbed. The motorbase consist of motor plate, side supports, pretensioning device and rubber suspension elements. Other sizes, ATEX- and special versions on request. For motor sizes not listed, please contact us.
