MÄDLERMÄDLER· Mechanics & transmission
Combined filter-regulator without shut off valve, port G1/4
Manufacturer part no. 83000100
$645.26≈ 558.47 €
Price summary
Listed by MÄDLER at €558.47. Delivered to France, including shipping, VAT and any customs duty, it comes to about €688.16. Prices last checked on 2026-08-05.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
On backorderlead time 14 d
Estimated landed cost
| Item | €558.47 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €114.69 |
| Total delivered | €688.16 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 1.122 kg |
Other characteristics
| Connection | G 1/4″ |
| Material | Polycarbonate |
| Shut off valve | Without |
| Surface | Blank |
Description
Material: Bowl: Polycarbonate. Housing: Zinc die-cast. O-ring seals: synthetic elastomers. Filter element: Polypropylene. Medium: Compressed Air. Operating temperature: -20°C to 65°C. For temperatures below +2°C please take the air properties into account. Operating pressure: max. 10 bar. Pressure range: 0.3 to 10 bar. Relief valve: Standard with relief valve. Pressure Gauge: Standard. Filter element: 40 micrometer standard. Bowl size (oiler): 0.04 litre. Max. flow: 13 l/s (connection G1/4, inlet pressure 10 bar. Set pressure: 6.3 bar, Øp = 1 bar). Draining: Manual. Oiler version: Micro-fog oiler.
