Mounting feet set including screws for worm gear screw jacks NPT and NPK size 4 length 230mm
Manufacturer part no. 47500411
Manufacturer part no. 47500411
Listed by MÄDLER at €101.50. Delivered to France, including shipping, VAT and any customs duty, it comes to about €139.80. Prices last checked on 2026-08-07.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
| Item | €101.50 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €23.30 |
| Total delivered | €139.80 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
| Weight | 1.8 kg |
| B1 | 230 mm |
| B10 | 13.5 mm |
| B11 | 20 mm |
| B12 | 150 mm |
| B2 | 204 mm |
| B3 | 30 mm |
| B4 | 16 mm |
| B5 | 13 mm |
| B6 | 13.5 mm |
| B7 | 115 mm |
| B8 | 145 mm |
| B9 | 15 mm |
| Size | 4 |
| Size of screw head | 7 mm |
| Screw norm | DIN 7984 |
Material: Steel St52, zinc-plated. Fastening strip set incl. screws for fastening the gearbox to the top or bottom side. NPK version C requires longer screws (not included). 1) For worm gear screw jacks NPK version B, the mounting strips must be machined to fit the square tube.
Semantically close products available for less — check the specs match your need.
| Screw size |
| M12 x 25 |
