Travelling nut for worm gear screw jack NPT version C size 2 with trapezoidal thread Tr. 20×4
Manufacturer part no. 47500216
$138.04≈ 119.60 €
Price summary
Listed by MÄDLER at €119.60. Delivered to France, including shipping, VAT and any customs duty, it comes to about €161.52. Prices last checked on 2026-08-07.
Delivered cost is an estimate for a single item shipped to mainland France; the seller's checkout is authoritative.
On backorderlead time 14 d
Estimated landed cost
| Item | €119.60 |
|---|---|
| Shipping | €15.00 |
| VAT (20%) | €26.92 |
| Total delivered | €161.52 |
Estimate for a single item delivered to mainland France, shipped from outside the EU: customs duty and clearance fees may apply and are charged by the carrier.
Datasheets & documents
Specifications (automatically extracted)
Mechanical
| Weight | 400 g |
Other characteristics
| E1 | 12 mm |
| E2 | 44 mm |
| F1 | 55 mm |
| F2 h9 | 32 mm |
| F3 | 45 mm |
| F4 | 32 mm |
| Size | 2 |
| Suitable adapter block part number | 64 470 232 |
| Suitable cardan adapter part number | 64 470 132 |
| D4 | TR. 20×4 |
| Mounting hole | 6 x Ø7 |
Description
Material: Bronze CuSn12-C-GC (2.1052). Preferred installation position for compressive force: with the flange facing downwards (compressive load on the flange instead of tensile load on the screws).
